DTSD1088-D
DTSD1088 Three Phase Direct Meter
Three phase direct-connected smart meter for small commercial and light industrial installations. Provides comprehensive energy measurement with communication capabilities for AMI integration.
Key Features
- Direct connection up to 100A
- Active and reactive energy measurement
- Multi-tariff support (up to 8 tariffs)
- Demand profile recording
- Tamper detection and event logging
- Modular communication interface
- DIN rail mounting option
Technical Specifications
| Voltage | 3×230/400V AC |
| Current Range | 10(100)A |
| Accuracy Class | Class 1 (IEC 62053-21) |
| Frequency | 50Hz / 60Hz |
| Communication | RS485 / PLC / NB-IoT |
| Display | LCD with backlight |
| Standards | IEC 62052-11, IEC 62053-21 |
| Operating Temperature | -25°C to +55°C |
| Enclosure Rating | IP54 |
Request a Quote for DTSD1088 Three Phase Direct Meter
Contact our product specialists for detailed pricing, datasheets, and compliance certificates for the DTSD1088-D.
